Bullet Resistant Laminated Glass UL752 Level 8 Bullet Resistance
Ray-Bar supplies ballistic glass with UL752 Level 8 rifle bullet resistant glazing. Level 8 bullet resistant glazing is ideal for a wide range of safety and security installations. (UL752 Level 8 bullet resistance is equal to NIJ 0108.01 Level 3 requirements.)
Glass with our rifle resistant glazing is proven to withstand a 7.62 x 51/308 Winchester round, with no spall. Our bullet resistant laminated glass provides 61% visible light transmittance.
These 1-15/16” thick bullet resistant laminated glass panels consist of an abrasion-resistant polycarbonate glaze on both sides of a multi-ply laminated glass sheet with PU (polyurethane) interlayers. We provide glass with rifle resistant glazing in custom sizes up to 70” x 130.
Features of Ray-Bar Bullet Resistant Laminated Glass
- UL752 Level 8 bullet resistance
- Level 3 bullet resistant glazing also available
- Rifle resistant glazing over multi-ply glass sheet with PU interlayers
- 1-15/16” total thickness
- Resists 7.62 x 51/308 Winchester round, no spall on asset side
- 61% visible light transmittance
- Sizes up to 70” x 130”—contact us to discuss your cut-to-size requirements
Bullet Resistant Glazing Certifications
- UL752 Level 8
- NIJ 0101.01 Level 3
- ASTM 1036-97
- ANSI 297.1
- CPSC 16 CFR 120 Cat 2
- ASTM 1349-96
- ASTM 1036-1
Contact Us for Complete Ballistic Glass Solutions
In addition to Level 8 bullet resistant laminated glass, Ray-Bar also provides a full line of ballistic products and bullet resistant glass for safety and security installations. Request a quote on glass with bullet resistant glazing, or contact us to learn more.
